The YS spiral conveyor presser is suitable for the treatment of grille residues in urban sewage treatment plants, residential area sewage pretreatment units, municipal rain/sewage pumping stations and waterworks, etc. , which is mainly used in conjunction with equipment such as grilles to convey, press and dewater the grille residues.

This equipment adopts a shaftless spiral type. When the material enters from the feeding hopper of the conveying and pressing machine, it is pushed and slid by the rotation of the spiral blades and sent along the U-shaped conveying trough to the compaction area. Under the reverse spring pressure of the pressing pipe and the discharge door cover, the grille residue is pressed and dehydrated. The dehydrated grille residue is forced to open the pressure plate and fall into the garbage cart for transportation. The squeezed seepage flows back into the grid well through the return water pipe.

1. Drive device adopts shaft-mounted parallel shaft spiral gear reducer, with compact structure, smooth and safe operation;

2. The U-shaped groove is provided with inner lining, with strong wear resistance and long service life;

3. It adopts the structure form of shaftless spiral blades and outlet pressure-type door panel, which integrates conveying, pressing and dewatering;

4. The conveyor frame is fixed with expansion bolts without the need for embedded parts;

5. The equipment can be linked with the supporting equipment for convenient control and can also be equipped with a local control box by itself.
