The PD belt conveyor is suitable for the chemical, metallurgical, coal mining, hydropower, building materials and other sectors, which can convey various bulk materials such as block and granularity. Therefore, it is often used in conjunction with grille or dewatering machines in urban sewage to convey grille residue or dewatered sludge.

The equipment is a continuous trough-shaped belt type. The material falls onto the conveyor belt through the discharge port of the grid or dehydrator. Under the drive of the electric drum, the material moves from one end to the other, and the end is connected to the trash can for further processing.

1. Reliable equipment operation, large conveying capacity, long conveying distance, multi-point loading and continuous conveying, etc.

2. The drive device adopts oil-cooled electric drum with protection grade IP55, compact structure, small floor space and easy maintenance;

3. The equipment adopts a spiral tensioning device to ensure the safe, reliable and effective operation of the conveyor belt;

4. The conveyor belt is made of nitrile rubber and adopts vulcanized joints that are easy to clean, corrosion-resistant and have a long service life;

5. The upper trough-shaped support rods are equipped with slag-blocking plates on both sides to prevent the grainy sewage from flowing and overflowing, and to clean the environment;

6. Easy operation, no clogging, easy maintenance, it can be arranged horizontally or conveyed at an inclination angle,and it is ideal equipment for conveying grid residue;

7. The equipment can be interlocked with the supporting equipment for convenient control and can also be equipped with a local control box by itself.
