The XZY rotary regulating weir gate is mainly used for regulating water levels in irrigation, flood control, water conservancy and hydropower, sewage treatment plant water level control systems, which is also suitable for all water level regulating parts such as distribution wells and sedimentation tanks in alternating operation oxidation ditch sewage treatment as well as for regulating water levels or liquid levels in structures such as air flotation tanks, oil separators and other water conservancy projects.

This equipment is of rotary type. The hoist drives the upper lead screw of the weir gate. Through the vertical displacement up and down of the lead screw, the hinge machine pulls the gate body to change the angle with the liquid surface, thereby achieving the purpose of changing the water level and controlling the flow rate.

1.It features flexible operation, good sealing performance and a high degree of automation.

2. Strong adaptability to the working environment and long service life;

3. It is equipped with travel limit and power overload protection, work safety and reliability;

4. It is easy to assemble structures and convenient for installation and maintenance.
