The WJT type perforated plate screen cleaner consists of several sets of perforated plates mounted on a rotating screen chain. Driven by a motor reducer, the screen chain is driven by sprockets to perform a rotary motion against the water flow to intercept and lift debris. When the screen chain reaches the upper part of the screen, the debris on the perforated plates falls onto the conveyor by gravity. The WJT type perforated plate screen cleaner can accurately complete the entire work cycle, and its structural design ensures the cleaning effect, with no dead corners for debris accumulation at the bottom of the screen. This equipment is mainly suitable for removing fine solid debris below 10mm from water after coarse screens.

1. During the process of trash interception and slag cleaning, it is completed by the upward rotation of the mesh.
       2. When in motion, the displacement height is the vertical elevation of one mesh plate, which is completed by the waterborne and underwater transmission mechanisms. The equipment has a compact and reasonable structure, making it easy to maintain and manage.
       3. It is equipped with a cleaning brush and a high-pressure water flushing system, making the trash cleaning more thorough.
       4. The equipment is made of stainless steel, which is easy to replace, has good corrosion resistance, and a long service life.

1. Adopt the stepped sewage cleaning principle of the screen plate to avoid jamming and entanglement of debris;

2. The transmission parts are evenly distributed on the water surface support. There are no rotating parts underwater, which is convenient for maintenance and has a long service life;

3. There are a variety of materials for the movable and fixed grid plates to choose from, with a wide range of applications;

4. Adopt liquid level or time control to achieve automatic operation.
